What is a push-pull self-locking connector? What are its features and advantages?

　　The push-pull self-locking system is renowned worldwide for its simple and rapid mating and un-mating capabilities. It effectively withstands vibration and shock, and prevents accidental disconnection caused by pulling on the cable; it is absolutely safe and reliable in operation, making it ideal for use in environments with extremely limited space.

　　Push-pull self-locking circular connectors are widely utilized for signal connections in various equipment, including medical devices, electronics, instrumentation, and video processing systems. They are particularly well-suited for electrical signal connections in instruments and equipment that require frequent mating and un-mating, as well as those requiring shielding.

　　Technical Specifications of Push-Pull Self-Locking Connectors:

　　Current Rating: 1A – 35A. The current-carrying capacity varies depending on the size of the contact pins; larger pins are capable of handling higher currents.

　　Voltage Rating: 150V – 3500V. The voltage rating varies based on the specific insulator material used and the thickness of the gold plating on the contact pins. Generally, a higher number of contact pins results in a lower maximum voltage rating, and thinner gold plating also results in a lower maximum voltage rating.

　　Mating Cycles: Ranging from 1,000 to 20,000 cycles. This figure depends on the material used for the locking latch (spring clip). Connectors made of plastic materials typically offer a mating life of approximately 1,000 to 3,000 cycles. Metal connectors feature locking latches made from various materials, such as brass, annealed brass, or beryllium copper. Brass latches typically last for 3,000 to 5,000 cycles; annealed brass lasts for approximately 5,000 cycles; and beryllium copper lasts for approximately 5,000 to 20,000 cycles. Locking latches made of stainless steel offer a significantly higher mating life, averaging between 20,000 and 50,000 cycles.

　　Product Advantages of Push-Pull Self-Locking Connectors:

　　1.  Features an intelligently designed keying system that prevents mismating (blind insertion) and offers a variety of keying configurations.

　　2. Push-pull self-locking mechanism allows for simple and rapid connection and disconnection. (Features a non-slip surface design on the housing and an audible click to indicate proper engagement during self-locking.)

　　3. The all-metal structural composition provides effective electromagnetic shielding capabilities.

　　4. A precision-engineered self-locking mechanism ensures a secure and reliable connection.

　　5. Compact and sophisticated structural design. (Effectively conserves equipment space and facilitates the realization of miniaturized device designs.)
